Wholesale High temperature resistance ceramic refractory ball Manufacturers, Suppliers

Refractory ball with smooth surface, corrosion resistance, wear resistance, high strength, thermal conductivity and thermal capacity, high thermal efficiency, good thermal stability and storage temperature change is not easy to fracture, etc. Refractory ball usually used in shift converter and reformer in ammonia plant. Refractory ball has a lot of advantages, such as: High strength, long use period. Chemical stability, it won't react with the materials. Good performance of resistance high temperature, resistance high temperature up to 1900℃.

Product Description

Technical Specification of Refractory Ball

Index Unit Data
Al2O3 % ≥ 65
Fe2O3 % ≤ 1.6
Pore Volume % ≤ 24
Compressive Strength kg/cm² ≥ 900
Refractoriness °C ≥ 1800
Bulk Density kg/m³ ≥ 1386
Specific Gravity kg/m³ ≥ 2350
Refractoriness Under Load of 2kg/cm² °C ≥ 1500
Loss on Ignition (LOI) % ≤ 0.1

Frequently Asked Questions

Q What is the minimum Al2O3 content in these refractory balls?
The chemical composition contains an Al2O3 (Alumina) content of ≥ 65%, ensuring high thermal stability and chemical resistance.
Q What is the maximum refractoriness temperature limit?
The refractory balls have a refractoriness rating of ≥ 1800 °C, making them suitable for severe high-temperature industrial environments.
Q What is the compressive strength rating?
The compressive strength is rated at ≥ 900 kg/cm², providing superior mechanical support and resistance against crush or breakdown under load.
Q How do these refractory balls perform under physical load at elevated temperatures?
Under a mechanical load of 2 kg/cm², the refractoriness under load rating remains ≥ 1500 °C, preventing structural deformation during high-heat operations.
Q What are the bulk density and specific gravity properties?
The bulk density is ≥ 1386 kg/m³ with a specific gravity of ≥ 2350 kg/m³, reflecting high density and optimal structural compactness.
Q What is the pore volume and Loss on Ignition (LOI) standard?
The pore volume is strictly maintained at ≤ 24%, with a Loss on Ignition (LOI) value of ≤ 0.1%, ensuring high purity and minimal volatile components.
