It has a high temperature and high pressure resistance, bibulous rate is low, the characteristics of the chemical performance is stable. Can withstand the erosion of acid, alkali and other organic solvents, and can endure in the production process of temperature changes. Its main function is to increase gas or liquid distribution points, support and protection intensity is not high activity of the catalyst.
| Al2O3 | Fe2O3 | MgO | SiO2 | Na2O | TiO2 |
|---|---|---|---|---|---|
| >99% | <0.1% | <0.5% | <0.2% | <0.05% | <0.05% |
| Item | Value |
|---|---|
| Water absorption (%) | <1 |
| Packing density (g/cm3) | 1.9-2.2 |
| Specific gravity (g/cm3) | >3.6 |
| Operation temp.(max) (℃) | 1650 |
| Apparent porosity (%) | <1 |
| Moh's hardness (scale) | >9 |
| Acid resistance (%) | >99.6 |
| Alkali resistance (%) | >85 |
| Size | Crush Strength | |
|---|---|---|
| kg/particle | KN/particle | |
| 1/8" (3mm) | >203 | >2 |
| 1/4" (6mm) | >459 | >4.6 |
| 1/2" (13mm) | >877 | >8.7 |
| 3/4" (19mm) | >1220 | >12 |
| 1" (25mm) | >1630 | >16 |
| 1-1/2" (38mm) | >2340 | >23 |
| 2" (50mm) | >3460 | >34 |
| Size and tolerance (mm) | ||||
|---|---|---|---|---|
| Property | Specifications | |||
| Size | 3 / 6 / 9 | 9 / 13 | 19 / 25 / 38 | 50 |
| Tolerance | ± 1.0 | ± 1.5 | ± 2 | ± 2.5 |
The main function is to increase gas or liquid distribution points, and to provide support and protection for catalysts with low activity intensity.
The maximum operation temperature is up to 1650℃, maintaining high thermal and structural stability even under severe production temperature variations.
It features stable chemical performance with an acid resistance exceeding 99.6% and alkali resistance greater than 85%, effectively withstanding corrosion from acids, alkalis, and organic solvents.
A 1" (25mm) ball provides a crush strength greater than 1630 kg/particle (or >16 KN/particle), ensuring exceptional structural support under high pressure.
The product exhibits high mechanical hardness with a Moh's hardness scale >9, an apparent porosity of <1%, and a very low water absorption rate of <1%.
Besides containing >99% Al2O3, impurity contents are minimal: Fe2O3 is <0.1%, MgO is <0.5%, SiO2 is <0.2%, and both Na2O and TiO2 are below 0.05%.
