| Model | 5A | |||||
| Color | Light gray | |||||
| Nominal pore diameter | 5 angstroms | |||||
| Shape | Sphere | Pellet | ||||
| Diameter (mm) | 1.7-2.5 | 3.0-5.0 | 1.6 | 3.2 | ||
| Size ratio up to grade (%) | ≥98 | ≥98 | ≥96 | ≥96 | ||
| Bulk density (g/ml) | ≥0.72 | ≥0.70 | ≥0.66 | ≥0.66 | ||
| Wear ratio (%) | ≤0.20 | ≤0.20 | ≤0.20 | ≤0.20 | ||
| Crushing strength (N) | ≥45/piece | ≥100/piece | ≥40/piece | ≥75/piece | ||
| Static H2O adsorption (%) | ≥22 | ≥22 | ≥22 | ≥22 | ||
| Water content (%) | ≤1.0 | ≤1.0 | ≤1.0 | ≤1.0 | ||
| Typical chemical formula |
0.7CaO · 0.3Na2O · Al2O3 · 2SiO2 · 4.5H2O SiO2 : Al2O3 ≈ 2 |
|||||
| Typical application |
|
|||||
| Package | Carton box; Carton drum; Steel drum | |||||
| MOQ | 1 Metric Ton | |||||
| Payment terms | T/T; L/C; PayPal; West Union | |||||
| Warranty | a) By national standard GB_13550-1992 | |||||
| b) Offer lifetime consultation on problems occurred | ||||||
| Container Specifications | 20GP | 40GP | Sample Order | |||
| Quantity | 12MT | 24MT | < 5kg | |||
| Delivery time | 3 days | 5 days | Stock available | |||
Molecular sieve Type 5A can be regenerated by either heating in the case of thermal swing processes; or by lowering the pressure in the case of pressure swing processes.
To remove moisture from a 5A molecular sieve, a temperature of 250-300°C is required. A properly regenerated molecular sieve can give moisture dew points below -100°C, or mercaptan or CO2 levels below 2 ppm.
The outlet concentrations on a pressure swing process will depend on the gas present, and on the conditions of the process.
5A - Zeolites are available in beads of 1-2 mm (10x18 mesh), 2-3 mm (8x12 mesh), 2.5-5 mm (4x8 mesh) and as powder, and in pellet 1.6mm, 3.2mm.
To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
